BLOW MOLDING MACHINE
-
-> Stretch Blow Moulding Machine Type : Semi Automatic blowing M/c
Model. : PP-2000.
Capacity : 800 Bottles/Hr
Capacity to be : 1 ltr & 1.5 ltr.
Maximum product weight : 50 gms
Maximum mould size : 150 MM
Material to be Used : Pet Pre-form.
Total power Consumption : 4.0 KW
Heating Power : 3.4 KW
Maximum Product diameter :100 MM
Neck Diameter : 19 MM to 32 MM
Volume of Product : 100 ML to 2000ML
Air compressor : 12.5 HP
Blowing pressure : 14 KG/CM2.
Required Air : 35 CFM
Required Man Power : 2 Person.
Weight of M/c : 600 Kgs
